A 5,000- 6,000 Btu/hr air conditioner drawing about 500 watts can be installed in one window of a designated cool room (it is important that the installation is insulated and well-sealed
A Corsi-Rosenthal Box is a highly effective DIY air cleaner made of easy to obtain materials such as HVAC filters, a box fan, cardboard, and tape
A direct-vent sealed-combustion fireplace takes its combustion air directly from outside through a dedicated air inlet and vents combustion products directly outside
A direct-vent sealed-combustion furnace has dedicated pipes for combustion air and exhaust
A heat pump clothes dryer is a type of condensing clothes dryer that uses heat pump technology to efficiently dry clothes
A natural gas 94% efficiency tankless hot water heater provides endless hot water.
A portable CO monitor is used to test for ambient CO near a ventless combustion fireplace
A portable power meter shows the power usage of equipment; e.g., this laptop is drawing 12 watts while idle
A refrigerator is secured to the wall by use of an angle bracket with lag bolts, expansion bolts and metal screws
A simple kit for anchoring a TV, appliance, or furniture to a wall may include straps, attachment hardware, and screws for attaching both to the appliance and to the wall
A water heater and furnace are protected from flood waters by a concrete floodwall, with a shielded, gasketed door.
A water heater is anchored to 2 x 4 wood blocking that is attached to the wall studs.
An in-line exhaust fan supplements the ability to exhaust moisture-laden air and lint from a dryer
An indoor water heater should be secured to the wall’s studs to prevent it from moving or tipping over in the event of an earthquake
An innovative U-shaped heat pump offers SEER 15 efficiency and operation with smart phones
At the outlet of the dryer exhaust duct, install a hooded vent with a louvered damper
Basic components of a gas tankless water heater include a high-powered burner, fan, and heat exchanger; condensing gas water heaters also have a secondary heat exchanger and a piped air intake to the sealed combustion chamber
Because flue temperatures are cool, intake and exhaust ducts on a Category 4 direct-vent sealed-combustion condensing furnace can be made of PVC
Because heat pump clothes dryers recycle the hot air in the drum rather than venting it, they use 70% less energy than conventional electric clothes dryers while drying clothes in the same amount of time
Category III oil-fired, sealed-combustion boiler configured as a direct-vented appliance that draws its combustion air from outside
Clothes dryers vented directly to outdoors, except for ventless dryers equipped with a condensate drain
Compare gas tankless water heater efficiencies on the Energy Guide labels or look for the ENERGY STAR label
Cooling setting adjustments on a refrigerator allow the unit to be tuned to meet the target temperature for energy efficiency
Dryer exhaust duct should vent directly to the exterior via a smooth, rigid metal duct
Dryer vent is run vertical with a 90 degree bend and does not vent to the outside
Earthquake-ready home actions include securing cabinets, shelves, and heavy furniture or electronics to walls and preparing utilities for disruptive movement.
ENERGY STAR appliances like the dishwasher and refrigerator save energy and money for consumers.
For fireplaces that are not mechanically drafted or direct-vented to outdoors, total net rated exhaust flow of the two largest exhaust fans is .15 CFM per 100 sq. ft. of occupiable space when at full capacity
Furnaces, boilers, and water heaters located within the home’s pressure boundary are mechanically drafted or direct-vented
Furniture and heavy household items should be anchored to prevent tipping over during an earthquake and for everyday use if small children are in the home
Heavy-gauge metal strapping can be used to secure water heaters and other appliances
Many hardware stores sell appliance bracing kits to secure the water heater to wall framing with metal straps
