A central fan-integrated supply system uses a fresh air intake ducted to the home's central furnace or air handler unit to supply fresh air throughout the home
All return air and mechanically supplied outdoor air pass through filter prior to conditioning
Filter access panel includes gasket or comparable sealing mechanism and fits snugly against the exposed edge of filter when closed to prevent bypass
Filter located and installed so as to facilitate access and regular service by the owner
Furnace filter resistance varies by surface area; deeper pleats add surface area
Furnace filters that are MERV 6 or higher protect the HVAC equipment and improve indoor air quality
If filter is inaccessible, locate the air filter between the return air plenum and the air handler box
If furnace is accessible, locate the air filter between the return air plenum and the air handler box
If the furnace is hard to access, locate filters at return registers covered by hinged grilles that are easy to open from inside the home
Install a filter with a MERV rating of 6 or higher in each ducted mechanical system
Install the filter media box between the return air plenum and the air handler box
Leaks at the air filter cover panel can draw in unconditioned or undesirable air
Locate the fresh air intake away from pollution sources and in an easily accessible location
Replace HVAC air filters regularly to protect the equipment and maintain system efficiency
Right - Ducts and heat pump cabinet are properly sealed with mastic, high MERV filter is installed, and duct and refrigerant lines are air sealed at ceiling.
Right – HVAC furnace filter is properly installed in cabinet with gasketed cover to prevent air leakage
The air handler of the air-to-water heat pump is equipped with a very high efficiency air filter and a damper-controlled fresh air intake.
The airflow direction is labeled on the edge of the filter to ensure it is properly oriented when installed.
The blower wheel (fan) on this ductless wall-mounted indoor unit has accumulated dust and mold - a common issue for this design.
The edge of this 1-inch HVAC filter indicates it's dimensions, allowing proper matching of filter to air handler
The MERV rating, particle capture efficiencies, and pressure drops are printed on the side of this 1-inch pleated filter
This ductless wall-hung indoor unit has supplemental air filters (outlined in red), which only filter a portion of the airflow; most of the air bypasses the supplementary filters and only passes through the standard mesh filters.
To increase surface area and reduce pressure drop for high MERV filters, the return duct can be constructed to permit the installation of two furnace filters side by side
Wrong - Air filter was compressed and may not function effectively to filter return air.
