A supplemental dehumidifier is integrated with the home’s HVAC air handler to provide extra dehumidification when needed
A ventilation controller with a manual override is located on a central air handler fan that is located in an accessible location
Air flow is produced when central HVAC fan is energized (set thermostat to “fan”)
An elevator shaft vent with a motorized damper in a multistory multifamily building provides smoke and hot gas control in an elevator shaft during fire events; during normal operation the damper remains closed to reduce energy loss.
Continuously-operating ventilation & exhaust fans include readily accessible override controls
Cool air flow is produced when the cooling cycle is energized (set thermostat to “cool”)
Cooling setting adjustments on a refrigerator allow the unit to be tuned to meet the target temperature for energy efficiency
Ductless indoor units like this one are controlled individually by handheld remote controllers.
Example of a home computer station where an advanced power strip might be used with a computer, monitor, and speakers
Example of an entertainment center where an advanced power strip might be used to control a DVD, game console, and speakers
Function of ventilation controls is obvious (e.g., bathroom exhaust fan) or, if not, controls have been labeled
Heated air flow is produced when the heating cycle is energized (set thermostat to “heat”)
Internet-enabled lighting controls are part of many home automation systems and can increase safety and security as well as energy efficiency.
Pressure manometers are used to determine the level of pressurization and rate of leakage when conducting blower door testing and building diagnostics
Right - The automated ventilation system has a sensor built in switch that can detect indoor air pollution; if it senses a rise in humidity, VOCs, smoke, carbon dioxide, or small particulates, the system will turn on the nearest fan to eliminate pollution
Right – Smart equipment for homes may include a tablet or touchpad from which the homeowner can control lighting, HVAC, window shades, security, music, and other home automation features.
Right – The builder provided adequate wall space for the solar inverter next to the home’s electric panels.
Right – This bath fan runs continuously at low speed and is activated by a motion sensor to operate a higher speeds.
Right – This plug-in sensor detects indoor air quality issues in a home, including elevated levels of humidity, VOCs, smoke, carbon dioxide, or small particulates; if detected, the sensor can switch on the nearest exhaust fan to remove the pollutants.
Right- An electronic controller operates an exhaust fan, a mechanical damper on a fresh air intake, and the central heat pump’s fan, which draws in fresh air through the damper and distributes it in sync with exhaust fan operation for balanced fresh air.
The green-lit panel next to the fan and light switches is an indoor air quality sensor that will automatically turn on the exhaust fan if it detects a rise in humidity or indoor air pollutants.
The ventilation controller is next to the thermostat and has a manual override button
This bath exhaust fan ventilation control can be set by the HVAC technician for continuous operation, delayed shut off, or a set amount of minutes each hour
This damper located at the top of a stairwell in a multistory building is automatically kept closed to reduce energy loss; it automatically opens during a smoke event.
This home’s balanced fresh air system includes a filtered fresh air intake that is wired to the central HVAC system with timer controls while exhaust fans in the kitchen, bathrooms, and laundry room pull stale and moist air from the home.
This multistory stairwell has an automatic damper that is integrated with the engineered smoke control system.
Three-zone ductless mini-split system consisting of two wall-mounted and one ceiling-mounted indoor ductless units and one outdoor unit
Three-zone mini-split system consisting of one wall-mounted ductless unit, one ceiling-mounted ductless unit, and one ducted indoor unit, all connected to one outdoor unit
